NbTi superconducting wire
NbTi  is a binary alloy with good processing plasticity, high strength, low critical magnetic field, mainly used for magnetic fields below 10T. The main fields of application are nuclear fusion experimental reactor, high-end medical equipment (magnetic resonance MRI), nuclear magnetic resonance spectrometer (NMR), photovoltaic manufacturing field (magnetically controlled Czochralski monocrystalline silicon MCZ) and proton/heavy particle accelerators. The parameters in the following list are conventional products, we can also provide cost-effective customized products according to customer needs.
Niobium-titanium Monolith line
0551-65613662
kuafuchaodao@163.com
Parameter
Product specification
0.45mm~1.00mm
Copper ratio range
1.0~4.0
Critical current(@5T,4.2K)
160A~500A
Niobium-titanium Monolith line
0551-65613662
kuafuchaodao@163.com
Parameter
Product specification
1.2x0.75mm~1.32x0.86mm
Copper ratio range
1.0~4.0
Critical current(@5T,4.2K)
400A~900A
Niobium-titanium WIC wire (wire in Channel)
0551-65613662
kuafuchaodao@163.com
Parameter
Product specification
1.98x1.17mm~2.55x1.77mm
Copper ratio range
7~10.5
Critical current(@4T,4.2K)
500A~1200A
Low loss niobium-titanium wire (ITER class)
0551-65613662
kuafuchaodao@163.com
Parameter
Product specification
0.73mm
Copper ratio
2.3
Critical current(@5T,4.2K)
340A
